This easy-to-setup Bundle offers a quality fingerprint scanner and a software application (FbF® bioCollect) that captures and saves the fingerprint images. The Futronic FS88H fingerprint sensor is an FBI-certified scanner that quickly captures crisp, clear fingerprint prints.

The Fingerprint Capture Bundle contains the following components:

Qty. 1 - FbF® bioCollect Biometric Capture Application

Simple, color-coded user interface walks you through each step of fingerprint and image capture
Windows 10 or 11 (not for Mac OSX)
Save fingerprints to the same location automatically
Complies with 1:1 export ratio requirement

Qty. 1 - Futronic FS88H FIPS201/PIV USB Fingerprint Sensor

Precise optics - allow the scanning of practically undistorted fingerprint images
Infra-red illumination - allows scanning of wet, dry, blurred and other problematic fingers
Rugged sensor - thick (16 mm) crown glass used for platen. Practically indestructible scanner surface
Complies with 500dpi image capture requirement

Support:

All new purchases of this product include 90 days of no-cost support. Following this period, additional technical assistance is available through our Single Support Incident or Annual Maintenance & Support Plan options.

Futronic FS88H Optical Fingerprint Scanner

Physical	Size: 66 x 66 x 29mm Weight: 150 g Operation temperature: -10 to + 55°C 2M standard USB cable Supply voltage: C 4.5-5.5 V via USB port Power consumption: Active <900mW, Standby <200mW, Sleep mode <4mW ESD contact - 8KV no permanent damage ESD air discharge - 16KV no permanent damage
Fingerprint Sensor	Window size: 16.26 x 24.38mm Image resolution: 320x480 pixels, 500 DPI, 8 bit grey level Fingerprint image size: 56K Live Finger Detection (LFD) feature
PC Requirements	Windows 10, 11
Certifications	FCC, CE, RoHS
Standards/Compliance	IPS 201/PIV 071006 Image Quality Specification, Microsoft WHQL

FbF bioCollect

Operating System	Windows 10, 11
Processor	1 gigahertz (GHz) or faster 32-bit (x86) or 64-bit (x64) processor
Memory Requirements	1 gigabyte (GB) RAM (32-bit) or 2 GB RAM (64-bit)
Required Disk Space	Approximately 100 MB
Database	50 MB of empty space on Hard drive
Software Requirement	Microsoft .NET 4.0 or higher
